    Main Front Chuck Rear Feeding Chuck Double Acting Pneumatic Rotary Chuck

    Ask Lasest Price
    Brand Name : Lingman
    Model Number : G600J-225
    Price : USD 3400-3800/set
    Payment Terms : T/T, L/C
    Supply Ability : 500 sets per month
    Delivery Time : 15-20 work days
    • Product Details
    • Company Profile

    Main Front Chuck Rear Feeding Chuck Double Acting Pneumatic Rotary Chuck

    Main Front Chuck, Rear Feeding Chuck Double Acting Pneumatic Rotary Chuck
    1. Descripition

    This laser chuck has a simple structure, few components, light weight, low failure rate, stable performance, small moment of inertia and low energy consumption. The axial dimension of the chuck is small, and the cost for realizing the zero tailings si lower. At the same time, it also saves the cost of production. This laser chuck is widely used in tube-sheet itegrated machines, like model 3105.


    2. Performance Parameters
    • Model number
    G600J-225
    • Claw stroke
    220mm
    • Maximunm clamping force
    1.7KN
    • Allowable pressure
    0.4-0.9MPa
    • Limit speed
    500r/min
    • Clamping range
    0-220mm
    • Central height
    350mm
    • Rotational inertia
    6.5Kg.m2
    • Rotating part weight
    129kg
    • Whole unit weight
    177kg


    3. Dimensions
    Main Front Chuck Rear Feeding Chuck Double Acting Pneumatic Rotary Chuck

    SpecificationsABB1CDEFGHIRS
    G600J-22552035068069017912046018522528012-M818


    4. Advantages

    a. Full stroke design
    b. Wide range of applications, diversification of processing profiles
    c. High repetitive positioning accuracy
    d. Low maintenance cost, long service life

    e. Multiple configurations are available
    e. 1 Solid or hollow

    e. 2 Comb-type or mortise-groove type claws



    5. Production Line
    Main Front Chuck Rear Feeding Chuck Double Acting Pneumatic Rotary Chuck

    6. Our Service

    1.We are the direct factory with good price and fast lead time.
    2.Professional design team work with you.

    3.Professional QC team to guarantee the high quality.

    4.Providing OEM & ODM service.

    7. FAQ

    Q: What parameters should we offer us for proper quotation?

    A: Application, dimension, quantity, packing requirements.


    Q:What's your advantages?

    A:Honest business with competitive price and professional service on export process.


    Q: Can we visit your company to inspect products before delivery?

    A: You are welcome to visit our company to inspect us and our products.

    Q:What's your lead time?
    A: Within 15-35 days after confirming the order.

    Q: What are your payment terms?

    A: T/T, L/C, West Union, Paypal, etc.
